Maximum machining length:

3000mm

Maximum machining width:

300mm

Maximum machining height:

300mm

Power of spindle:

6kW/7.5kW(Tool Changing)

Tool shank:

ISO 30

Spindle RPM:

24000rpm

X-axis speed:

60m/min

Y-axis speed

40m/min

Z-axis speed

30m/min

Reposition accuracy:

±0.05mm/m

Precision of cutting length

±0.1mm/m

Spindle and tool change system

Air cooling

X-axis drive

German Dual gear rack and pinion and linear guide

Y / Z axis drive

Japan ball screw and linear guide

Operating system

WINDOWS XP，GERMAN KINGSKY profiles professional software ( read PLT or DXF to achieve processing automatically)

Tool detection

Automatic measurement of tool length/ automatic tool sensor

Dimension (L × W × H)

3800×2000×2050mm

Installation of rotary C-axis:

The workpiece can realize machining of three sides for one-time clamping, -90 degrees to 90 degrees, the minimum setting angle: 0.5 degree, accuracy ± 0.1 degree

Installation of automatic tool change and tool magazine

Time of tool change: 5~10s

Capacity of tool magazine: 8+1

Security and protective devices

Photoelectric protection in operation, milling scrap recycling device, movable loading workbench, assembled with sound-absorbing protective panel

Tool detection

Automatic measurement of tool length/automatic tool sensor

Clamping work platform

3set/4set/6set

Tool accessories

ISO30 tool bit/ Clamps / Tool

Bar code scanners and supporting software

For mass production, the profile data are automatically read, automatically implement the same machining procedure

Machine weight

2500kg
