KS-ZW202-Automatic Multi-bits Double head Drilling Machine

KS-ZW202-Automatic Multi-bits Double head Drilling Machine



It adopts Italian mature design concept and application of the latest operation requirements and practice, mainly used for multi holes processing at two ends of Aluminum Alloyed materials and PVC materials simultaneously; It can punch Max. Eight holes simultaneously with single action, thus ensures the precision of multi holes at two ends and improves efficiency effectively.

TECHNICAL PARAMETER
Model and parameters
KS-ZW202 Automatic Multi-bits Double head Drilling Machine
Processing width
400~2000mm
φ3-φ11
The distance of two apertures
20-420mm
Motor power
2.2Kw X 2
Rotating speed of Motor
2800rpm
Working air pressure
0.6-0.8Mpa
Working voltage
380VAC/50HZ
Overall Dimension (L*W*H)
3650×800×1220 mm
Weight of machine
1050kg
